Integrated GA45 Oil Injected Screw Compressor Durable Multi Function

Rotary Screw Atlas Copco GA Series oil injected air compressor

GA 45 Premium Compressor

• High performance Free Air Delivery.
• Premium quality at the lowest initial investment.
• Integrated refrigerant dryer.
• Standard Elektronikon ® controller (optional Touch controller).

(A)

Integrated highly efficient R410A dryer
• Excellence in air quality.
• 50% reduction in energy consumption compared to traditional dryers.
• Zero ozone depletion.
• Incorporates optional UD + filter according to Class 1.4.2.

(B)

NEOS drive
• Atlas Copco’s in-house designed inverter for GA VSD compressors.
• IP5X protection degree.
• A robust, aluminum enclosure for trouble-free operation in the harshest conditions.
• Fewer components: compact, simple and user-friendly.

(C)

Cubicle cooling booster
• Cubicle in overpressure minimizes ingress of conductive dust.
• Electrical components remain cool, enhancing lifetime of components.

(D)

Elektronikon ® for remote monitoring
• Integrated smart algorithms reduce system pressure and energy consumption.
• Monitoring features include warning indications, maintenance scheduling and online visualization of machine’s condition.

(E)

Heavy-duty air intake filter
• Protects the compressor components by removing 99.9% of dirt particles down to 3 microns.
• Differential inlet pressure for proactive maintenance while minimizing pressure drop.

Advanced Elektronikon ® Touch controller
• Improved user-friendliness: 4.3-inch high-definition color display with clear pictograms and service indicator.
• Internet-based compressor visualization using a simple Ethernet connection.
• Increased reliability: new, user-friendly, multilingual user interface.

Key features:
• Automatic restart after voltage failure.
• Built-in SMARTLINK online monitoring.
• Dual pressure set point.
• More flexibility: four different week schedules that can be programmed for a period of 10 consecutive weeks.
• On-screen Delayed Second Stop function and VSD savings indication.
• Graphical service plan indication.
• Remote control and connectivity functions.
• Software upgrade available to control up to 6 compressors by installing the optional integrated compressor controller.

High reliability and smart energy
GA 30+ & GA 37/45

1,Maintenance-free drive system
• 100% maintenance-free; totally enclosed and protected against dirt and dust.
• Suitable for harsh environments.
• High-efficiency drive arrangement; no coupling or slippage losses.
• Standard up to 46°C/115°F and for high ambient version 55°C/131°F.

2,IE3 Premium Efficiency electrical motors
• IP55, insulation Class F, B rise.
• Non-drive side bearing greased for life.
• Oil lubricated drive side bearings.

3,Robust spin-on oil filter
• High-efficiency, removing 300% smaller
particles than a conventional filter.
• Integrated bypass valve with the oil filter.

4,Separate oversized oil cooler and aftercooler
• Low element outlet temperatures, ensuring long oil lifetime:• Removal of nearly 100% condensate by mechanical separator.
• No consumables.
• Eliminates possibility of thermal shocks in coolers.

5,Advanced control & monitoring via Elektronikon®
• Integrated smart algorithms reduce system pressure and energy consumption.
• Monitoring features include warning indications,maintenance scheduling and online visualization of machine’s condition.

6,Heavy-duty air intake filter
• Protects the compressor components by removing 99.9% of dirt particles down to 3 microns.
• Differential inlet pressure for proactive maintenance while minimizing pressure drop.

7,Electronic no-loss water drain(optional)
• Ensures constant removal of condensate.
• Manual integrated bypass for effective condensate removal in case of power failure.
• Integrated with compressor’s Elektronikon® with warning/alarm features.

8,Radial fan
• Low noise level. • High flows.
• Compact design.

9,Integrated highly efficient R410A dryer
• Excellence in air quality.
• 50% reduction in energy consumption compared to traditional dryers.
• Zero ozone depletion.
• Incorporates optional UD+ filter according to Class 1.4.2.

Integrated Oil Injected Screw Compressor

Oil Injected Screw Compressor Durable

Multi Function GA45 Compressor
