Atlas Copco heatless regenerative PSA dryer C/CD/CD+ capacity 18m3/min~114m3/min
Dry, clean air: reliable, safe production
The C series heatless regenerative adsorption dryer uses a desiccant to absorb the moisture in the compressed air. The machine consists of two identical towers, which switch functions after the cycle ends.
When one tower is in the adsorption state, the other tower is in the regeneration state, and the regeneration gas needs to consume a certain proportion of the finished compressed air.
When using the dew point control function, the switching time will be further extended to maximize energy savings.
Depending on the pressure dew point, the dryer can choose alumina or molecular sieve material, and the lowest pressure dew point can reach -70 degrees Celsius.
Features & Benefits
1. The C series heatless regeneration adsorption dryer is especially suitable for the application environment with small starting capacity;
2. Excellent energy efficiency ratio comes from low pressure design and efficient adsorbent material;
3. High-end hardware configuration ensures stable and reliable performance and minimal maintenance;
4. The direction of incoming and outgoing pipes can be freely reversed 180 degrees to connect;
5. The sonic nozzle is installed at the back end of the dryer to prevent overflow of the dryer. When the dryers are used in parallel, the air volume of each dryer is uniform.
